Global Drive Cam Loader
About this Manual
Conventions used
1 About this Manual
This Manual contains information about the Lenze Global Drive Cam Loader V1.1.
The Cam Loader is a software which is used to transfer recipes consisting of motion
profiles, cam tracks and position markers from a PC to Lenze target systems.
Special features of the Cam Loader are:
[ Import of CAD data via standardised interfaces (VDI 2143).
[ Program operation via an easy-to-use PC user interface for the first commissioning and
preparation of additional functions to be provided to the user by the mechanical
engineer.
[ Program control by means of script files from an IPC for automated processes without
additional user entries and recipe extensions through the user.
[ Smoothing of imported CAD data (motion profiles) for a smoother running of the
drives.
[ Recording of all important events.
1.1 Conventions used
This Manual uses the following conventions to distinguish between different types of
information:
Type of information Marking Examples/notes
Variable name italics Set bEnable to TRUE to...
Window pane The message window... / The Options dialog box...
Control element bold The OK button... / The Copy command... / The Properties tab... / The
Name input field...
Sequence of menu
commands
If the execution of a function requires several commands, the individual
commands are separated by an arrow: Select File W Open to...
Keyboard command Use to call the Online Help.
If a command requires a combination of keys, a "+" is placed between
the key symbols:
Use + to...
Program listings
Courier
IF var1 < var2 THEN
a = a + 1
END IF Keyword
Courier
bold
Link underlined Links are highlighted references which are activated by means of a
mouse click.
Safety information
)}
4Layout of the safety information (^ 6)
Step-by-step
instructions
X
Like safety information, step-by-step instructions and tips can be
recognised by an icon.
Tip
I
