Global Drive Cam Loader
User interface
Language selection
20 1.1 EN - 05/2005
L
5.2 Language selection
You can always select another language for the menu, dialog and help texts of the Cam
Loader.
[ The available languages depend on the language files that have been installed
together with the Cam Loader.
X
How to select another language...
1. Select the command ViewWSelect language.
2. Go to the Language configuration dialog box and select the desired language.
3. Click OK to confirm your selection and close the dialog box.
5.3 Title bar
The title bar at the top of the application window shows the program icon and the program
name on the left and the window icons on the right.
[ With a click on the Window icons 0 1 2 0 1 2 0 1 2 0 1 2 you can change the representation of the
application window as follows:
– Icon in the task bar (0
0 0 0)
– Full screen (1 1 1 1)
– Window size (2 2 2 2)
[ A click on the program icon opens the system menu which also includes commands for
positioning and changing the size of the application window.
[ A click on the window icon r or a double-click on the program icon closes the Cam
Loader.
5.4 Menu bar
The menu commands of the Cam Loader can be accessed via the menu bar.
[ A click on an item of the main menu opens the corresponding menu and lists the menu
items contained in it.
[ Click a menu item to execute the corresponding function.
– Menu items which are displayed in light gray are currently deactivated because the
execution of the corresponding function would not make any sense in the current
program state.
I
Tip!
Many frequently used functions can be executed faster by means of the
Toolbar
icons.
(^ 21)
