Global Drive Cam Loader
Control via script files
Script files
7.2.1 Master settings
Section [CamLoader]
7.2.2 Product settings
Section [ProductXXX]
7.2.3 Slave settings
Section [SlaveXXX]
Key Parameter
NumberOfSlaves Number of slaves
NumberOfProducts Number of products (motion profiles)
MasterName Name of the master
MasterUnit Unit of the master
MasterMinimum Minimum of the master
MasterMaximum Maximum of the master
MasterGear1 Gear factor of the master (numerator)
MasterGear2 Gear factor of the master (denominator)
MasterFeed Feed constant of the master
MasterIncrement Increments of the master
MasterCycles Cycles of the master [cycles/min]
Key Parameter
Name Name of the product
Number Product number
ID Product ID
Key Parameter
Name Name of the slave
Unit Unit of the slave
Minimum Minimum of the slave
Maximum Maximum of the slave
Gear1 Gear factor of the slave (numerator)
Gear2 Gear factor of the slave (denominator)
Feed Feed constant of the slave
Increment Increments of the slave
NumberOfCurves Number of motion profiles (products)
Points Number of points per motion profile
DataModel Data model
0 = Relative data model
1 = Absolute data model
