Installation of the e93zwl2 air lock – Lenze E93ZWLX User Manual
Page 44
Installation of the E93ZWL2 air lock
Preparations at the top of the control cabinet
16
l
E93ZWLX DE/EN/FR 1.0
4.3.2
Drill fixing holes for air locks into top of control cabinet
0
1
1
2
0
0
1
Æ
4.8 mm
93ZWL005
Air lock
Top of control cabinet
Mounting plate
1. Insert the air locks into the recesses in the top of the control cabinet.
2. Drill 16 fixing holes for each air lock.
3. Take the air locks out of the top of the control cabinet.
