Installation Luftschleuse E93ZWL2
Antriebsregler und Luftschleusen montieren
18
l
E93ZWLX DE/EN/FR 1.0
1
4
3
1
0
2
2
93ZWL006
Ringösen
Montageplatte
Federring M8
Antriebsregler
Innensechskantschraube M8 × 25 mm
1. Antriebsregler auf Montageplatte legen.
2. Antriebsregler jeweils mit 6 Innensechskantschrauben und Federringen genau an den
gezeigten Punkten auf der Montageplatte befestigen.
