Installation of the e93zwl air lock – Lenze E93ZWLX User Manual
Page 35
Installation of the E93ZWL air lock
Preparations at the top of the control cabinet
7
l
E93ZWLX DE/EN/FR 1.0
3.3.2
Drill fixing holes for air lock into top of control cabinet
0
1
1
2
0
0
1
Æ
4.8 mm
93ZWL015
Air lock
Top of control cabinet
Mounting plate
1. Insert the air lock into the recess in the top of the control cabinet.
2. Drill 16 fixing holes.
3. Take the air lock out of the top of the control cabinet.
