Communication manual 8400 protec PROFINET
Parameter reference
Parameters relevant for communication
C13865
C13867
Parameter | Name:
C13865 | Display: Most recent safety PRM data
Data type: OCTET_STRING
Index: 10710
d
= 29D6
h
Display of the most recently sent F_parameters. This data is only valid if PROFIsafe is active.
• The coding of the F_parameters is described in the PROFIsafe profile V2.0.
;
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Bytes
Information
0
Slot
1
2
Subslot
3
4
Recldx
5
6
Accepted length
...
9
10
F_parameter
...
24
Parameter | Name:
C13867 | Display: Most recent diagnostic data
Data type: OCTET_STRING
Index: 10708
d
= 29D4
h
Display of most recently diagnostic data sent by the controller:
;
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Bytes
Information
0
Slot
1
2
Subslot
3
4
Error code
...
7
8
Slot
9
10
Subslot
11
12
Error code
...
15
