Communication manual 8400 protec PROFINET
Technical data
General data and operating conditions of the PROFINET
3
Technical data
3.1
General data and operating conditions of the PROFINET
3.2
Protocol data
Mounting instructions "Inverter Drives 8400 protec"
Here you can find information on general technical data, operating conditions,
and rated data of the device.
Field
Values
Communication profile
PROFINET
Communication medium
S/FTP (Screened Foiled Twisted Pair, ISO/IEC 11801 or EN 50173), CAT 5e
Interface
RJ45: Standard Ethernet (in accordance with IEEE 802.3), 100Base-TX (Fast
Ethernet) or M12-socket
Network topology
Tree, star, and line
Number of nodes
Max. 255 in the subnetwork
Max. cable length
100 m
PROFINET node
IO device with real time (RT) communication properties
PUO ID number
0x0106
Device identification (Device ID)
0x8420
Baud rate
100 Mbps
Switching method
"Store and forward"
Switch latency
125 μs at maximum telegram length
Field
Values
Process data words (PCD)
Max. 16 process data words (max. 32 bytes)
PROFIsafe data
4 words (8 bytes)
Acyclic parameter data channel
Limited by the PROFINET frame size
