2.2.2. Rated data of axis modules
Axis module type
9222_E
9223_E
9224_E
9225_E
Order no.
33.9222_E
33.9223_E
33.9224_E
33.9225_E
Output current
(f
ch
= 8 kHz)
[A
eff
]
4.5
5.5
13.5
18
Output current
(f
ch
= 16 kHz)
[A
eff
]
2.3
2.9
6.9
9.5
Peak current
(for t = 5 s at f
ch
= 8 kHz;
for t = 2.5 s at f
ch
= 16 kHz)
[A
eff
]
8
10
24
33
Permanent power
(V
A
= 3 x 480 V and f
ch
= 8 kHz)
[kVA]
3.7
4.5
11.2
14.9
Permanent power
(V
A
= 3 x 480 V and f
ch
= 16 kHz)
[kVA]
1.9
2.4
5.7
7.9
Peak power
(V
A
= 3 x 480 V)
[kVA]
6.6
8.3
19.9
27.4
Output voltage V
A
[V]
3 x 0...V
mains
Field frequency
[Hz]
0...
±
300
Speed
[min
-1
]
0...
±
8000
Power loss at permanent power
[W]
200
250
340
510
Power loss at controller inhibit
[W]
45
45
45
125
Weight
[kg]
9.2
9.5
9.5
20.5
Type
9226_E
9227_E
9228_E
Order no.
33.9226_E
33.9227_E
33.9228_E
Output current
(f
ch
= 8 kHz)
[A
eff
]
25
32
46
Output current
(f
ch
= 16 kHz)
[A
eff
]
13
16.5
23.5
Peak current
(for t = 5s at f
ch
= 8kHz;
for t = 2.5 s at f
ch
= 16kHz)
[A
eff
]
45
57
82
Permanent power
(V
A
= 3 x 480 V and f
ch
= 8 kHz)
[kVA]
20.2
26.6
38.2
Permanent power
(V
A
= 3 x 480 V and f
ch
= 16 kHz)
[kVA]
10.8
13.7
19.5
Peak power
(V
A
= 3 x 480 V)
[kVA]
37.4
47.3
68.1
Output voltage V
A
[V]
3 x 0...V
mains
Field frequency
[Hz]
0...
±
300
Speed
[min
-1
]
0...
±
8000
Power loss at permanent power
[W]
640
800
1000
Power loss at controller inhibit
[W]
125
125
125
Weight
[kg]
21
22
22
