59
5.2. LECOM status messages
•
C068 Operating state
Bit no. Signal
0, 1, 2, 3 Operating fault
4, 5, 6, 7 Communication fault
8 RFR enable
9 Qmin
10 running
11 IMP
12 QSP
13 Imax
14 Nact = Nset
•
C069 Controller state
Bit no. Signal
0 BALARM
1 CALARM
2 PCHG
3 REMOT
4 AUTO
5 RESET
6 XXX
7 RFR
15 TRIP
•
C067 Fault numbers of the operating faults (see "Service")
--- OC1 OC2 OC5 OUE OH1 OH2 U15 CCr Pr Sd2 EEr UEr
0 11 12 15 22 51 52 70 71 72 82 91 92
Further information on the serial communication LECOM1
(LECOM-A/B) can be obtained from the Operating Instructions
LECOM-A/B.
For extensions, the following modules are available:
•
2101 Interface with mains isolation for RS422/RS485
•
2122/2123 Interface for optical fibres (LECOM-LI)
