6. Code table
The following table shows which settings can be performed with
which codes. Detailed explanation about the codes and the
functions which can be achieved, are described in special chapters.
For the acceptance of parameters see page 41.
How to read the code table:
Column Short form Meaning
Code C000
C017*
C043 (L) Code digit of the standard code set
Code digit of the extended code set
Code digit can only be reached via the LECOM interface; code
is not displayed
Parameter -0- The factory setting is printed in bold.
Acceptance ON-LINE
SH + PRG
Unit immediately accepts new parameter
Unit accepts new parameter after pressing SH+PRG
Unit accepts parameter only if the controller is inhibited when
pressing SH+PRG.
Code Name Parameter Accept-
ance see
page
C000 Code set -0-
-1-
-2-
-9-
-11-
-P-
xxx
Standard code set read only
Standard code set
Extended code set
Service code set (service password
neccessary)
Code set for
automation module
Password request
Enter password SH+PRG
password
SH+PRG
45
C001 Operating
mode
-0-
-1-
-2-
-3-
-4-
-5-
-6-
-7-
Control: Parameter setting:
Terminals Keypad
Keypad Keypad
Terminals LECOM1
LECOM1 LECOM1
Terminals LECOM2
LECOM2 LECOM2
LECOM2 Keypad
LECOM2 LECOM1
45
C002 Load parameter
set -0- Factory setting
C003 Store
parameter set -1- Parameter set 1 SH+PRG
C004 Switch-on
display 51 Code no. for parameter displayed
after first switch-on SH+PRG 57
