5.3. Table of attributes
If you want to programme the parameter setting or superimposed
drive and control functions yourself, the following table will inform
you about serial communication via LECOM1 (LECOM A/B) or
LECOM2.
Legend
Code Meaning
Code Lenze code number
DS Data structure
E = Single variable (only one parameter element)
A = Array variable (several parameter elements can be selected by
the code for the preselection or by LECOM sub code.)
I = Image variable (several parameter elements can only be
selected by the code for preselection).
P/S Parameter setting/control (corresponding to C001)
P = Parameter setting
S = Control
DT Data type
B8
= 1 byte bit coded
B16 = 2 byte bit coded
VS = ASCII string
FIX32 = 32-bit-value with sign;
decimal with four decimal places
Examples:
1.2 = 12000FIX32-dez 00002EEOFIX32-hex
-10.45 = -104500FIX32-dez FFFE67CCFIX32-hex
N16 = 16-bit value with sign; 0 = 0; 100% = 214
100% = 16384N16-dez
4000N16-hex
-50% = -8192N16-dez E000N16-hex
DL Data length in byte
LCM-R/W Access authorization for LECOM
Ra
= Reading always permitted
W = Writing permitted under certain conditions
(e.g. operating mode, controller inhibit)
Wa = Writing is always permitted
LCM1-
Form. LECOM A/B-format
(see technical description LECOM A/B)
AIF-PZD Process data in the automation interface.
Mapping on LECOM2 process data channel is possible.
PD = Process data
LCM2-
Index Number (index) under which the parameter is addressed when using
LECOM 2.
