Wiring the device modules – Lenze E94ARNE User Manual
Page 57
Wiring the device modules
Communication modules
l
57
EDK94ARN24 DE/EN/FR/ES/IT 2.1
Displays
Pos.
Colour
State
Description
MS
Green
On
The communication module is supplied with voltage.
DE
Red
On
The communication module is not accepted by the basic
device (see notes given in the documentation for the
basic device).
Signals at connection X215/X216:
−
Yellow
On / blinking
Data is being exchanged via Ethernet.
−
Green
On
Ethernet connection is available.
