Technical data, Electrical data, Output data (on the dc side) – Lenze E94ARNE User Manual
Page 47: Rated data for internal brake chopper
Technical data
Electrical data
l
47
EDK94ARN24 DE/EN/FR/ES/IT 2.1
Output data (on the DC side)
Voltage
Frequency
Current [A]
Number of
phases
[V]
[Hz]
max. +45 °C
max. +55 °C
E94ARNE0134
In motor mode
325/565/705
0 (DC)
32/32/32
24/24/24
2
In generator mode
345/586/727
0 (DC)
16/16/16
12/12/12
2
E94ARNE0244
In motor mode
325/565/705
0 (DC)
57/57/57
43/43/43
2
In generator mode
345/586/727
0 (DC)
28.5/28.5/28.5
21.4/21.4/21.4
2
Temperature in the control cabinet
Voltage
Output power X109, X110, +UG, −UG
Type
[V]
with mains filter P
aDC
[kW]
E94ARNE0134
in motor mode
325/565/705
8.6/15/18.6
in generator mode
345/586/727
4.3/7.5/9.3
E94ARNE0244
in motor mode
325/565/705
15.6/27/33.8
in generator mode
345/586/727
7.8/13.5/16.9
Power loss P
V
[W]
Type
Total (when operating with I
aN
)
Constant (control electronics only)
E94ARNE0134
150
40
E94ARNE0244
230
40
Rated data for internal brake chopper
Type
Brake resistor
(min −10%)
Peak current
(0.5 s)
Peak braking
power
(0.5 s)
Cont.
current
Continuous
braking power
Voltage [V]
AC
DC
R
BR
[
W]
I
BRmax
[A]
P
BRmax
[kW]
I
BRd
[A]
P
BRd
[kW]
E94ARNE0134
230
345
18.0
19.2
6.6
9.4
1.6
400
586
27.0
21.7
12.7
10.6
3.0
500
727
27.0
26.9
19.6
13.2
4.7
E94ARNE0244
230
345
9.0
38.3
13.2
21.7
4.2
400
586
18.0
32.6
19.1
18.4
6.1
500
727
18.0
40.4
29.4
22.9
9.4
