Cablaggio del modulo asse 6, Diagnostica/tastiera, Resolver – Lenze E94ARNE User Manual
Page 154: Collegamento di sistema per la sincronizzazione
Cablaggio del modulo asse
l
154
EDK94ARN24 DE/EN/FR/ES/IT 2.1
Diagnostica/Tastiera
Connettore X6
Siglatura
Descrizione
Interfaccia interna, connettore RJ69, per tastiera o adattatore per
diagnostica
9400SSP000X6
Resolver
Connettore X7
Siglatura
Descrizione
1
+REF
2
−REF
3
V
CC
4
+COS
5
−COS
6
+SIN
7
−SIN
8
+KTY
9400SSP000X7
9
−KTY
Collegamento di sistema per la sincronizzazione
Connettore X8
Siglatura
Descrizione
1
Esclusivamente per l’utilizzo obbligatorio con il filtro di rete
E94AZMR0xx4xDB, X324
...
9400SSP000X8
15
