15
Leica CM3600 XP – Cryomacrotome
2.2.3 Dimensions and weight
Inner (cryochamber L x H x W):
1650 x 720 x 600 mm
Outer (L x H x W):
2800 x 1090 x 920 mm
Total dimensions with connecting lines:
Outer length (total):
2800 mm
Outer length (chamber only):
1940 mm
Outer length (control unit only):
860 mm
Outer height (total):
1090 mm
Outer height (work surface height):
1050 mm
Outer width:
920 mm
Weight (total, incl. microtome):
660 kg
Weight (microtome only):
190 kg
2.2.4 Electrical connections
380 V / 50 Hz, three-phase
Nominal voltage:
380 V AC ± 10 %
Nominal frequency:
50 Hz
Line voltage tolerance:
± 10 %
Power draw:
2400 VA
Circuit breaker/
3 x 8A / 1 x 10A
Power safety switch
to DIN IEC 127-2
208 V / 60 Hz, two-phase
Nominal voltage:
208 V AC
Nominal frequency:
60 Hz
Line voltage tolerance:
± 10 %
Power draw:
2400 VA
Automatic cutout/
2 x 8A / 1 x 16A
Power safety switch
UL-listed
200 V / 50 Hz, two-phase
Nominal voltage:
200 V AC
Nominal frequency:
50 Hz
Line voltage tolerance:
± 10 %
Power draw:
2400 VA
Automatic cutout/
2 x 8A / 1 x 16A
Power safety switch
UL-listed
2.
Characteristics of the Leica CM3600 XP
