Kinze 3110 Mounted Planter Rev. 5/14 - Manual (Page 84)

Decals, Paint, and Miscellaneous
TO RELEASE SPRING ON RATCHET TIGHTENER ROTATE KNURLED SLEEVE TENSION 7100-295
7100-210 DRIVER
REAR SHAFT RIGHT SIDE TRANSMISSION DRIVEN
FRONT SHAFT
PROTECTED BY ONE OR MORE OF THE
FOLLOWING PATENTS: UNITED STATES
OTHER PATENTS PENDING
5,346,019 4,648,334 4,721,168 4,923,017 5,024,173 CANADA
7100-87
1,268,071-1990 1,294,852-1992 5,740,870 5,647,440 5,488,996
View A-A
Section B-B
B
B
A A
Uncontrolled movement of
planter components can cause
death, serious injury, or damage
to property and equipment.
Raise planter and install cylinder
lockups before folding. Fold on
level ground. Install wing safety
latches before towing.
7100-402
WARNING
WARNING
Improper operation or servicing
of this equipment can result in
death or serious injury. Read
and follow all instructions in the
Operator and Parts Manual.
Contact your Kinze dealer or go
to www.kinze.com to order a
replacement manual.
7100-387
ITEM PART NO . QTY . DESCRIPTION
1 G7100-404 1 Decal, Kinze
2 G7100-402 1 Decal, Warning
3 G7100-405 1 Decal, 3110
4 G7100-387 1 Decal, Warning
5 G7100-209
G7100-210 1
1 Decal, Transmission, L .H . Side
Decal, Transmission, R .H . Side
6 G7100-295 - Decal, Spring Tension Release
7 G7100-259 - Reflective Decal, Amber, 1½" x 9", Rectangular
1
2
3
4
5
6
7 7
