Kinze 3110 Mounted Planter Rev. 5/14 User Manual
Page 47
Digital Vacuum Gauge, Analog Vacuum Gauge, and Vacuum
Fan Assembly
ITEM
PART NO .
QTY .
(Per Assy .)
DESCRIPTION
1
GA11154
1
Digital Vacuum Gauge W/4-Pin Connector
2
GA11156
GD16224-01
GA11175
1
-
-
Sending Unit W/
¼
" Tubing And Harness W/4-Pin Male Connector
Tubing, ¼" x 45"
Strain Relief
3
GR1736
1
Hose Barb, 3/16" To ⅛" NPT
4
GD15849-02
1
Clear Plastic Tubing, 5/16" O .D . x 120"
5
GA10765
GR1777
1
-
Analog Vacuum Gauge W/Hose Barb
Hose Barb, ⅛" NPT To 3/16" Barb
6
GA10799
1
Breather, ⅛" Male NPT
7
G10001
G10108
1
1
Hex Head Cap Screw, ⅜"-16 x 1"
Lock Nut, ⅜"-16
8
G11215
3
Hex Socket Head Cap Screw, No . 6-32 x ⅜", Grade 8
9
GD15804
1
Mount
10
GD15803
1
Support
11
GA11157
1
Harness, 120"
12
GA11699
-
Extension Harness, 180"
13
GA17547
-
Power Adapter Cable
14
GA11155
GD14258
GD14660
G1K268
1
-
-
-
Harness W/Fuse Holder And Fuse, 132"
Fuse Holder
Fuse, 2 Amp Delay Action
Console Cable Connector Kit, Includes: (1) 3-Pin Connector, (1) Cable Clamp, (1)
Lock Ring, (3) Female Terminal Pins
15
GA8328
-
4-Pin Connector W/Female Housing, 4 Seals And 4 Pin Contacts
16
GA8329
-
4-Pin Connector W/Male Housing, 4 Seals And 4 Sockets
17
---
-
See “Vacuum Fan Hydraulic Motor Assembly” on page P47
18
G10599
G10229
G10101
2
2
2
Carriage Bolt, ⅜"-16 x 1¼"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
19
GA10148
1
Shroud
20
G11133
6
Hex Socket Head Cap Screw, 5/16"-18 x ¾", Grade 8
21
GD15789
1
Backing Plate
22
GA10635
1
Impeller
23
GD15790
1
Hub
24
G11391
G10499
1
1
Flat Washer, ⅝" SAE
Hex Jam Nut, ⅝"-18, Grade 2
25
GA10752
1
Cover
26
G11124
7
Whiz Lock Bolt, ⅜"-18 x 1"
27
GD14536
1
Manifold
28
G11123
6
Whiz Lock Bolt, ⅜"-16 x ¾"
29
G10063
G10753
G11387
G10108
2
2
2
2
Hex Head Cap Screw, ⅜"-16 x 4"
Hex Head Cap Screw, ⅜"-16 x 4½"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
30
GA11987
1
Screen
31
GD15863
1
Discharge Deflector
32
---
-
See “Vacuum Fan Motor Valve Block Assembly (Located Below Vacuum Fan
Assembly)” on page P48
A
GA10143
-
Vacuum Fan Assembly (Items 17-26 And 29-31)
M0244-02
Model 3110
Rev . 5/13
