Kinze 3110 Mounted Planter Rev. 5/14 - Manual (Page 57)

ITEM PART NO . QTY .
(Per Assy .)
DESCRIPTION
1 --- - See “Seed Rate Transmission and Module Drive Assembly” on page P57
2 GD8175
G11391
G10230
G10104 2
4
4
4 U-Bolt, 7" x 7" x ⅝"-11 (Diamond)
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
3 G10005
G11391
G10230
G10104 4
4
4
4 Hex Head Cap Screw, ⅝"-11 x 1¾"
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
4 GA7294
GD5804
GA7295
G10641
G10610 1
1
1
-
-
Arm W/Pin, Lower Clamp And Spring Pins
Pin, 1¼" x 12"
Clamp W/Grease Fittings
Grease Fitting, ⅛" NPT
Spring Pin, ⅜" x 2"
5 G10026
G11392
G10231 2
2
2 Hex Head Cap Screw, ¾"-10 x 2"
Flat Washer, ¾" SAE
Lock Washer, ¾"
6 GD10403 2 Concentric Spacer
7 GD10328 1 Adjustment Block
8 GA4705
G10117 1
2 Adjusting Screw
Hex Nut, 1"-8
9 GD7041
G10082
G10459 1
2
2 Pin, 1" x 4"
Flat Washer, 1" SAE
Cotter Pin, 3/16" x 1½"
10 G10026
G10231 2
2 Hex Head Cap Screw, ¾"-10 x 2"
Lock Washer, ¾"
11 G11081 - Hex Jam Nut, 1½"-12, Grade 2
12 GA0895 2 Bearing
13 GA2148
GR0434 1
-
Hub W/Cups, 6 Bolt
Cup
14 GR0270 6 Lug Bolt, 9/16"-18
15 GA2558
GD11490 1
-
Spindle W/Round External Retaining Ring, 9½"
Round External Retaining Ring
16 GD0844 1 Tire, 7 .60" x 15", 8 Ply (Specify Brand*)
17 GA5196 1 Wheel W/Valve Protector, 5" x 15"
18 GD1166 1 Valve Stem
A GA2147 - Hub And Spindle Assembly (Items 11, 12, 13, and 15)
B GA10660
GA10661
-
-
Ground Drive and Contact Wheel Assembly, R .H . (Items 1-18 On This Page, Items
2-15
See “Contact Drive Wheel Assembly” on page P55 , Items 1-10 And 12-40
See “Seed Rate Transmission and Module Drive Assembly” on page P57 and Items
2-20 See “Module Drive” on page P59
Ground Drive And Contact Wheel Assembly, L .H . (Items 1-18 On This Page, Items
2-15
See “Contact Drive Wheel Assembly” on page P55 , Items 1-10 And 12-40
See “Seed Rate Transmission and Module Drive Assembly” on page P57 and Items
2-20 See “Module Drive” on page P59
*Specific brand requests will be supplied only as available from current Kinze Repair Parts stock . If a specific brand
requested is not in stock, the brand available will be supplied .
Ground Drive Wheel Assembly
M0244-02 Model 3110
