Seed Rate Transmission and Module Drive Assembly
ITEM PART NO . QTY .
(Per Assy .)
DESCRIPTION
18 GA5105
GA5106
GA5107
GA5108
GA5109
GA5110
GA5111
GA5112
GA5113
1
1
2
2
1
1
1
1
1
Sprocket, 15 Tooth
Sprocket, 17 Tooth
Sprocket, 19 Tooth
Sprocket, 23 Tooth
Sprocket, 24 Tooth
Sprocket, 25 Tooth
Sprocket, 26 Tooth
Sprocket, 27 Tooth
Sprocket, 28 Tooth
19 GA7336
GD7426
GD1026
G11387
G10229
G10047
1
-
-
-
-
-
Idler W/Bolt-On Sprockets
Sprocket, 12 Tooth
Sleeve, 13/16" Long
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Head Cap Screw, ⅜"-16 x 1¾"
20 GA5548 1 Special Bearing
21 G3400-01 4 Flangette
22 GD10337 1 Shaft, ⅞" x 10 ½"
23 G10602 7 Spring Pin, ¼" x 1½"
24 G11100
G10227
G11385
1
1
1
Hex Socket Button Head Cap Screw, ¼"-20 x ½", Grade 8
Lock Washer, ¼"
Flat Washer, ¼" SAE
25 G2100-03 3 Bearing, ⅞" Hex Bore, Spherical
26 GA5202 1 Sprocket, 34 Tooth, See “Point Row Clutch” on page P63 , For Machines Equipped
With Point Row Clutches
27 G10233 - Machine Bushing, 1", 10 Gauge (As Required)
28 G10038
G10128
GB0258
G11389
G10228
G10102
1
1
1
1
1
1
Hex Head Cap Screw, ½"-13 x 3"
Machine Bushing, ½", 14 Gauge
Stepped Spacer, ⅞"
Flat Washer, ½" Plated SAE
Lock Washer, ½"
Hex Nut, ½"-13
29 GA7154 2 Sprocket W/Bearing, 18 Tooth
30 G10581
G10128
GD7889
G10228
G10102
1
1
1
1
1
Hex Head Cap Screw, ½"-13 x 2 ¼"
Machine Bushing, ½", 14 Gauge
Bushing . 1" O .D . x 9/16" I .D . x 7/16" Long
Lock Washer, ½"
Hex Nut, ½"-13
31 G10036
G11391
G10503
G10107
1
1
1
1
Hex Head Cap Screw, ⅝"-11 x 4"
Flat Washer, ⅝" SAE
Hex Jam Nut, ⅝"-11, Grade 2
Lock Nut, ⅝"-11
32 GD13422
GD13394
1
-
Idler Arm, R .H . Side Of Planter (Shown)
Idler Arm, L .H . Side Of Planter
33 G10033
G11389
G10228
G10102
1
1
1
1
Hex Head Cap Screw, ½"-13 x 3½"
Flat Washer, ½" Plated SAE
Lock Washer, ½"
Hex Nut, ½"-13
34 GD10407 1 Chain Support
35 G10303
G10232
G10106
12
12
12
Carriage Bolt, 5/16"-18 x 1"
Lock Washer, 5/16"
Hex Nut, 5/16"-18
36 GA10063 1 Module
37 --- - See “Contact Drive Wheel Assembly” on page P55
38 GD15696 2 Strap
39 --- - See “Ground Drive Wheel Assembly” on page P53
40 GD14595 1 Spring Tension Link
A G1K380 1 Wrap Spring Wrench Replacement Kit, Gold Collar, R .H . (Items 1-8 And 24) (Shown)
G1K381 - Wrap Spring Wrench Replacement Kit, Silver Collar, L .H . (Items 1-8 And 24)
M0244-02 Model 3110
9/12 P58
