Row marker hydraulic system – Kinze 3110 Mounted Planter Rev. 5/14 User Manual
Page 79
ITEM
PART NO .
QTY .
DESCRIPTION
1
---
-
2
G6801-06-08
GR1037
G6801-08
GR1037
2
-
-
-
Elbow W/O-Ring, 90°, 9/16"-18 Male JIC To ¾"-16 O-Ring, 6 Row 30"
O-Ring
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring, 6 Row 36"/38"/40" And
8 Row 30"/36"/38"/40"
O-Ring
3
G6801-06-08
GR1037
G6400-08
GR1037
G6400-08-04
GR1465
2
-
-
-
-
-
Elbow W/O-Ring, 90°, 9/16"-18 Male JIC To ¾"-16 O-Ring, 6 Row 30"
O-Ring
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring, 6 Row 36"/38"/40" And
8 Row 30"/36"/38"/40"
O-Ring
Connector W/O-Ring, ¾"-16 Male JIC To 7/16"-20 O-Ring, 6 Row 36"/38"/40" And
8 Row 30"/36"/38"/40"
O-Ring
4
*A1106
*A3114
*A1049
*A3154
-
-
-
-
Hose Assembly, ¼" x 130", 6 Row 30"
Hose Assembly, ⅜" x 156", 6 Row 36"/38"/40"
Hose Assembly, ⅜" x 160", 8 Row 30"
Hose Assembly, ⅜" x 196", 8 Row 36"/38"/40"
5
*A1168
*A3115
*A1013
*A1028
-
-
-
-
Hose Assembly, ¼" x 120", 6 Row 30"
Hose Assembly, ⅜" x 146", 6 Row 36"/38"/40"
Hose Assembly, ⅜" x 150", 8 Row 30"
Hose Assembly, ⅜" x 186", 8 Row 36"/38"/40"
6
*A3186
2
Hose Assembly, ⅜" x 56"
7
G6500-06
G6500-08-06
4
-
Swivel Elbow, 90°, 9/16"-18 Male JIC To Female, 6 Row 30"
Swivel Elbow, 90°, ¾"-16 Male JIC To 9/16"-18 Female, 6 Row 36"/38"/40" And
8 Row 30"/36"/38"/40"
8
G10001
2
Hex Head Cap Screw, ⅜"-16 x 1"
G10229
2
Lock Washer, ⅜"
9
---
-
See “Row Marker Sequencing/Flow Control Valve” on page P74
10
GD10205
1
Mounting Angle
11
G10017
2
Hex Head Cap Screw, ½"-13 x 1½"
G10111
2
Lock Nut, ½"-13
* Hydraulic hose is not stocked by Kinze Repair Parts, but can be made available on a special order basis . Call for quote .
Row Marker Hydraulic System
M0244-02
Model 3110
9/12
P76
