Kinze 3110 Mounted Planter Rev. 5/14 - Manual (Page 5)

Shank Assembly, Seed Tube, and Depth Adjustment
ITEM PART NO . QTY .
(Per Row)
DESCRIPTION
1 GD24545
G10003
G10108 2
3
4 Stop
Hex Head Cap Screw, ⅜"-16 x 1½"
Lock Nut, ⅜"-16
2 G10326 1 Hex Head Cap Screw, ⅜"-16 x 3¾"
G11387 1 Flat Washer, ⅜" SAE
3 G3303-98
G3303-108
G3303-16
GR0196
-
-
-
-
Chain, No . 41, 98 Pitch Including Connector Link (Mechanical)
Chain, No . 41, 108 Pitch Including Connector Link (EdgeVac)
Chain, No . 41, 16 Pitch Including Connector Link (Used W/Row Unit Extension
Brackets)
Connector Link, No . 41
4 GD11962 1 Idler
5 GD1026 1 Sleeve, 13∕16" Long
6 G10201 1 Special Washer, ⅜" x 1½" O .D .
7 GD1065 1 Idler Spring
8 GD7318 1 Sleeve, 1" Long
9 GD16245 1 Sun Shade (Rubber)
10 GD11845 1 Dust Cap
11 GD28390
G10312
G10620 1
2
2 Shield
Carriage Bolt, 5∕16"-18 x ¾"
Serrated Flange Nut, 5∕16"-18
12 --- - See “Gauge Wheels” on page P7
13 --- - See “KPM III Electronic Seed Monitor” on page P78
14 G10438 1 Hex Head Cap Screw, ½"-13 x ¾"
15 GB0265 1 Pivot Link, Depth Adjustment
16 GA10157 1 Shank W/Gauge Wheel Pivot Spindle And Set Screw
17 G11592
G11591 1
1 Hex Head Cap Screw, ⅜"-24 x 2¾", Grade 8
Nylon Lock Nut, ⅜"-24, Grade C
18 G10551
G10669 1
1 Clevis Pin, ¼" x 2½"
Hair Pin Clip, No . 22
19 G11015 2 Hex Washer Head Cap Screw, ⅜"-16 x 1¼"
20 GB0274 1 Cover, Depth Adjustment
21 GB0266
GD3612 1
-
Handle, Depth Adjustment
Cap Plug
22 GD10993 1 Spring
23 GB0267 1 Lever, Depth Adjustment
24 GD11259 1 Sleeve, ⅜" I .D . x ⅝" O .D . x 125∕32" Long
25 G10207 1 Washer, ⅞" O .D . x 13∕32" I .D . x .134" (If Applicable)
26 GD13361 1 Pin, ⅜" x 1⅔"
27 GB0285 1 Collar, Depth Adjustment
28 GD17014 1 Hose Guide
29 G10047
G11387
G10108 1
2-3
1
Hex Head Cap Screw, ⅜"-16 x 1¾"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
M0244-02 Model 3110
Rev . 5/14 P2
TM
