ITEM PART NO . QTY . DESCRIPTION
1 GD15792-10
GD15792-15 -
- Hose, 2" x 60"
Hose, 2" x 120"
2 GD14627 2 Coupler, 2", 6 Row 36"/38"/40"
3 G10676 2 Hose Clamp, No . 36
4 GA11065 2 End Cap, 2"
5 G11145 4-6 T-Bolt Clamp, 7"
6 GD15799 2 Manifold, 19 ½" Long (Open Both Ends)
7 GD15854 2-4 Clamp
8 GA11061 1 End, 4"
9 GA10808 2-4 Mount
10 GD7145
G10228
G10102 4-6
8-12
8-12
U-Bolt, 7" x 7" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
11 G10312
G10620 2-4
2-4 Carriage Bolt, 5/16"-18 x ¾"
Serrated Flange Nut, 5/16"-18
12 GD14626 - Elbow, 90°, 2"
13 GD15856-01
GD15856-02 2
-
Pipe, 6" x 14", 8 Row 30"
Pipe, 6" x 20", 8 Row 36"/38"/40"
14 GD15850 2 Manifold, 21" (Open One End)
15 G10037
G10228
G10102 4
4
4 Hex Head Cap Screw, ½"-13 x 1¼"
Lock Washer, ½"
Hex Nut, ½"-13
16 GA10767 1 Mount, L .H .
17 GA10768 1 Mount, R .H .
18 --- - See “Digital Vacuum Gauge, Analog Vacuum Gauge, and Vacuum Fan Assembly” on
page P43
19 GD15791-03 2 Hose, 4" x 46"
20 G11137 4 T-Bolt Clamp, 4 ¼"
21 GA11062 2 Guide, 4"
22 GA10824 2 Hose Protector
23 G10038
G11389
G10228
G10102
G10104 2
2
2
2
2 Hex Head Cap Screw, ½"-13 x 3" (At Transmission Assembly)
Flat Washer, ½" Plated SAE
Lock Washer, ½"
Hex Nut, ½"-13
Hex Nut, ⅝"-11 (At U-Bolt On Row Unit)
Manifolds and Distribution Hoses
M0244-02 Model 3110
9/12 P50
