Hopper Support and Meter Drive
ITEM
PART NO .
QTY .
(Per Row)
DESCRIPTION
1
GA2007
G10621
G10309
1
2
2
Hopper Hold Down Latch
Serrated Flange Nut, ¼"-20
Carriage Bolt, ¼"-20 x ⅝", Grade 2
2
GA10155
G10061
G11387
G10108
1
1
2
1
Hopper Support
Hex Head Cap Screw, ⅜"-16 x 3½"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
3
GD11239
G10602
G10567
1
1
1
Knob
Spring Pin, ¼" x 1½"
External Retaining Ring, ⅝"
4
G10752
G11391
G10412
2
2
2
Hex Head Cap Screw, ⅝"-18 x 2¼"
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-18
5
GB0218
2
Bushing, 21∕32" I .D . x ⅞" O .D . x 19∕32" Long
6
GB0314
2
Hopper Mount
7
GB0331
G10620
G10338
1
2
2
Clutch Adapter Plate
Serrated Flange Nut, 5∕16"-18
Carriage Bolt, 5∕16"-18 x 1¼"
8
GA10137
GA12143
1
1
Double Sprocket And Bearing, Drive Clutch, 11/19 Tooth (Mechanical)
Double Sprocket And Bearing, Drive Clutch, 11/28 Tooth (EdgeVac)
9
GD11413
1
Spring
10
GD15747
1
Shaft
11
GB0278
G10546
1
1
Coupler
Spring Pin, 3∕16" x 1¼"
A
GA12144
-
Meter Drive Assembly, 11/28 Tooth (Items 3 And 8-11) (EdgeVac Shown)
B
GA10151
-
Meter Drive Assembly Complete, 11/19 Tooth (Items 3 And 8-11)
