Kinze 3110 Mounted Planter Rev. 5/14 User Manual
Page 69
ITEM
PART NO .
QTY .
(Per Assy .)
DESCRIPTION
1
GR1450
GA8328
-
-
Harness W/4-Pin Connector, 60"
4-Pin Connector W/Female Housing, 4 Seals And 4 Pin Contacts
2
GR1447
GA8329
-
-
Harness W/4-Pin Connector, 152"
4-Pin Connector W/Male Housing, 4 Seals And 4 Socket Contacts
3
GA7165
-
Circuit Breaker, 12 Amp
4
GA7144
-
Two Position Switch
5
G1K267
-
Power Lead Adapter Connector Kit, Includes: (1) 3-Pin Connector, (1) Cable Clamp,
(3) Male Terminal Pins
6
G1K268
-
Console Cable Connector Kit, Includes: (1) 3-Pin Connector, (1) Cable Clamp, (1)
Lock Ring, (3) Female Terminal Pins
7
GA17547
1
Power Adapter Cable
8
GA7416
1
Wiring Harness, 288"
9
GD9530
-
Contact
10
GD9529
GD12726
-
-
Housing, Black
Housing, Red
11
G10996
-
Fork Terminal
A
GA8747
-
Control Box Assembly (Items 1-4 and 10)
Point Row Clutch Electrical Components
M0242-02
Model 3110
Rev . 5/13
P66
