Kinze 3110 Mounted Planter Rev. 5/14 - Manual (Page 73)

ITEM PART NO . QTY .
(Per Assy .)
DESCRIPTION
1 GD0453-04
GD0453-03
GD0453-08 1
-
-
Extension Tube, 60", 6 Row 36"/38"/40"
Extension Tube, 50", 8 Row 30"
Extension Tube, 65", 8 Row 36"/38"/40"
2 G11396 2 Flat Washer, 1¼" SAE
3 GA11591 1 Arm, First Stage
4 --- - See “Row Marker Cylinder, 6 Row 36"/38"/40" and 8 Row 36"/38"/40"” on page P73
5 GD15386
G10460 1
1 Pin, 1¼" x 7⅝"
Cotter Pin, ¼" x 2"
6 GD5875 1 Hose Clamp, 9/16" x 2½" x 2"
7 G10133
G10232
G10106
G10228
G10102 1
1
1
2
2 Hex Head Cap Screw, 5/16"-18 x 1½"
Lock Washer, 5/16"
Hex Nut, 5/16"-18
Lock Washer, ½"
Hex Nut, ½"-13
8 GA11767
G10640
G10460 1
1
2 Pin W/Grease Fitting, 1¼" x 9½"
Grease Fitting, ¼"-28
Cotter Pin, ¼" x 2"
9 G10879 4 Flanged 12 Point Bolt, ⅝"-11 x 2", Special Hardened
10 GA5130 1 Mount
11 GA11766
G10640
G10460 1
1
2 Pin W/Grease Fitting, 1¼" x 115/6"
Grease Fitting, ¼"-28
Cotter Pin, ¼" x 2"
12 GD2161
G10460 1
2 Pin, 1¼" x 8¼"
Cotter Pin, ¼" x 2"
13 GD2721 1 U-Bolt, 2" x 2" x ½"-13
14 GA5190
GA5188
GA5192 1
-
-
Arm, Second Stage, 35", 6 Row 36"/38"/40"
Arm, Second Stage, 46", 8 Row 30"
Arm, Second Stage, 67", 8 Row 36"/38"/40"
15 GD0752-41 - Sleeve, 1" (If Applicable)
Row Marker Assembly, Two-Fold Low Profile
6 Row 36"/38"/40", 8 Row 30", and 8 Row 36"/38"/40"
M0244-02 Model 3110
9/12 P70
