ITEM PART NO . QTY .
(Per Assy .)
DESCRIPTION
1 --- - See “Seed Rate Transmission and Module Drive Assembly” on page P57
2 G10040
G10103 1
1 Hex Head Cap Screw, ¼"-20 x 1¾"
Hex Nut, ¼"-20
3 GD5860 1 Bar
4 GD5857 1 Spring
5 G10069
G11386
G10106 1
1
1 Hex Head Cap Screw, 5/16"-18 x 2¼"
Flat Washer, 5/16" SAE
Hex Nut, 5/16"-18
6 GD13394
GD13422 -
1
Idler Arm, R .H . Side Of Planter (Shown)
Idler Arm, L .H . Side Of Planter
7 G10581
G10128
GD7889
G10228
G10102 1
1
1
1
1 Hex Head Cap Screw, ½"-13 x 2¼"
Machine Bushing, ½", 14 Gauge
Bushing, 1" O .D . x 9/16" I .D . x 7/16" Long
Lock Washer, ½"
Hex Nut, ½"-13
8 GA7154 1 Sprocket W/Bearing, 18 Tooth
9 G10064
G10227
G10103 1
1
1 Hex Head Cap Screw, ¼"-20 x 1"
Lock Washer, ¼"
Hex Nut, ¼"-20
10 G11028
G11391
GD3180-15
G10104
G11391
G10107 1
1
1
1
1
1 Hex Head Cap Screw, ⅝"-11 x 4½", Full Thread
Flat Washer, ⅝" SAE
Sleeve, ⅝" I .D . x ⅞" O .D . x 15/32" Long
Hex Nut, ⅝"-11
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-11
11 GA5105 1 Sprocket, 15 Tooth
12 G10602 7 Spring Pin, ¼" x 1½"
13 G10233 1 Machine Bushing, 1", 10 Gauge
14 GD0914-66
GD0914-86
GD0914-96
GD0914-126 -
-
-
- Hex Shaft, ⅞" x 66", 6 Row 30" (No Holes) (Two Per Planter)
Hex Shaft, ⅞" x 86", 6 Row 36"/38"/40" (No Holes) (Two Per Planter)
Hex Shaft, ⅞" x 96", 8 Row 30" (No Holes) (Two Per Planter)
Hex Shaft, ⅞" x 126", 8 Row 36"/38"/40" (No Holes) (Two Per Planter)
15 GD11045 2 Lock Clamp
16 G10130
G10923 2
2 Square Head Machine Bolt, 5/16"-18 x 1 ¾"
Flange Nut, 5/16"-18, No Serration
17 G3310-75
GR0912
GR0911 1
-
-
Chain, No . 40, 75 Pitch Including Connector Link And Offset Link
Connector Link, No . 40
Offset Link, No . 40
18 GA5114 1 Sprocket, 30 Tooth
19 GA2180 1 Hanger Bearing, ⅞" Hex Bore
20 G10004
G11387
G10229
G10101 2
2
2
2 Hex Head Cap Screw, ⅜"-16 x 1¼"
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Nut, ⅜"-16
A G1K269 - Lock Clamp Kit (Items 15 And 16)
Module Drive
M0244-02 Model 3110
9/12 P60
