4 Visualization
62
4.9 Batches/Plants
When recording batch processes, a distinction is made between the plant and
the batch.
The instrument can combine and record the data from up to 3 plants in
batches (batch report). The number of batches for a plant is not limited. The
instrument distinguishes between “current batch” and the most recently
“completed batch” for a plant. The number of plants that are used and the
texts in the batch template can be configured on the instrument or in the setup
program.
4.9.1 Current Batches
v This display shows the current data for the batch(es). Further information
about entering the texts in the left and right columns can be found in
Chapter 23 "Configuration – Batches/Plants".
The batch texts on the right-hand side can be entered with one of the
following options:
Edit batch
Change batch/plant Batch start/stop
(only if configured)
Close editing
Batch
status
