19 Configuration Report
19.2 External … Out of range
Overview
External
External determines whether an external report is run while the external signal
(External start) is set (HIGH).
External start
External start defines the start signal for the external report.
On
The external report is run.
H
Only one external report will be started in a group within
5
seconds, i. e. any external restart before the 5 seconds have
elapsed will be ignored. If the start signal is still present after
5
seconds, the external report will be started at once. If the start
signal is no longer present, the report will not be restarted.
