2 Instrument Description
36
Active
operating mode The active operating mode is shown in the diagram by different symbols
behind the current display for the diagram speed:
2.8.2 Eco mode
The parameters for Eco mode are set in the menu for normal operation.
However, Eco mode can be used for all three operating modes.
In Eco mode, the momentary values (current values) are recorded in a
predefined minimum storage cycle (independent of the tolerance band).
Operating mode Symbol
Normal
operation
Timed mode
Event mode
t1 t1
Tolerance band
t1 = storage through “Min. storage cycle” (forced storage).
The tolerance band is specified
with regard to the unit of the
analog channels (e.g. ± 1 °C).
