28 Web server
28.2 Online Visualization (All Visualizations Except Batches)
Data that are displayed correspond to the configured groups of the recorder.
The sample screen shows the web server's home page. This page can be
used to represent channels in the same manner as on the recorder's screen.
(Left) click to bring up the available menus of the recorder.
Alarm/event list
Visualization
Groups
Next channel
Next group
History
