28 web server – JUMO 706581 LOGOSCREEN nt Operating Manual User Manual
Page 205
205
28 Web server
Start page
The start page is automatically shown after a successful logon.
Distribution
The display of the web server is divided into two areas:
- Navigation
- Visualization area
Navigation
The individual pages can be accessed by clicking the left mouse button.
Online visualization
Online visualization of
the current batch reports
Start and configuration of the
4-fold view (QuadView)
Start page
