57
6 Electrical connection
6.4 Current load
Determining the maximum current without the setup program
The current consumption for each module is stated in the technical data. The currents can be
added until the maximum value of 8 A is reached (base unit and input/output modules connect-
ed to it).
Additional input/output modules must then be mounted on the right, next to a router module on
an additional DIN rail. In this case, the maximum admissible current consumption is also 8 A
(router module input/output modules connected to it).
Where applicable, a second power supply unit is required for the voltage supply to the router
module.
Base units
Input/output modules
Special modules
Operating, visualization, recording
Determining the maximum current with the setup program
The setup program determines how many modules can be installed alongside one another. If
the maximum current is exceeded, the user will be required to install additional modules on the
right next to a router module on an additional DIN rail.
Where applicable, a second power supply unit is required for the voltage supply to the router
module.
CAUTION!
The maximum current load of the plug-in connections is 8 A.
The system may be damaged if this current limit is exceeded.
Distribute modules between multiple DIN rails and also power supply units, if required.
Designation Current consumption
Central processing unit Max. 350 mA
Designation Current consumption
Multichannel controller module Max. 300 mA
Relay module 4-channel 120 mA
Analog input module 4-channel 130 mA
Analog input module 8-channel 80 mA
Digital input/output module 90 mA
Designation Current consumption
Router module 100 mA
Designation Current consumption
Multifunction panel 840 Max. 750 mA
