5 installation – JUMO 705040 mTRON T - Router Module Operating Manual User Manual
Page 39
39
5 Installation
6
After attaching the cover, position the end bracket (D) on the DIN rail and move to the left
against the cover (D6).
7
Fasten the end bracket (D) using a screwdriver (D7). For this purpose, ensure that the end
bracket and the cover are positioned flush against the final module.
Step
Activity
