1 Introduction
1.2.7 Power supply units
Power supply units 705090/...
• Voltage supply AC 100 V ... 240 V
• 150 % peak load capability (for typical 4 s)
• Minimum current inrush
• Floating DC-OK relay contact
• Efficiency up to 93.5 %
• Active power factor correction (PFC)
• Active filter against mains transients
• Quick connection due to spring-cage terminals
• Dimensions (W x H x D):
705090/05-33: 40 mm x 130.5 mm x 121.5 mm
705090/10-33: 60 mm x 130.5 mm x 121.5 mm
For further information: Refer to data sheet 705090
