6 Electrical connection
54
Analog input module 4-channel 705020
~ ~
Digital input
AC 30 V, DC 50 V
Analog input module 8-channel 705021
~ ~
~ ~
Router module 705040
System bus In AC 500 V
~ ~
System bus Out 1 AC 500 V
~ ~
System bus
24 V
Voltage supply
Power supply units 24 V 705090
DC 24 V
3800 V AC 230 V
~ ~
SELV DIN EN 50178
...
Analog input 1
Analog input 4
Special modules
Multifunction panel 840 705060
Operating, visualization, recording
Com 1
Com 2
USB host
USB device
Ethernet
System bus In
AC 30, DC 50 V
~ ~
AC 1500 V
~ ~
AC 1500 V ~ ~
AC 30 V, DC 50 V
Digital input/output module 12-channel 705030
~ ~
Digital input/output 1 to 12 AC 30 V, DC 50 V
System bus Out 2 AC 500 V
~ ~
System bus Out AC 1500 V ~ ~
AC 30, DC 50 V
~ ~
AC 30, DC 50 V
~ ~
AC 30, DC 50 V
~ ~
~ ~
AC 30 V, DC 50 V
AC 30 V, DC 50 V
Digital input
Analog input 1 to 8
~ ~
AC 30 V, DC 50 V
