HL

71


Level 2

Level 3

Parameter-level

Define the output value for channel 1
Possible parameters:
ActInt, ActExt, Power, Setpoint

The parameter flashes, switch by pressing

and

Select the scale for channel 1.

The value flashes. Set by using the
numeric keypad and confirm by pressing

.

The value flashes. Set by using the
numeric keypad and confirm by pressing

.

Define the output value for channel 2.
Possible parameters:
ActInt, ActExt, Power, Setpoint

The parameter flashes, switch by pressing

and

Select the scale for channel 2.

The value flashes. Set by using the
numeric keypad and confirm by pressing

.

The value flashes. Set by using the
numeric keypad and confirm by pressing

.
