Operating controls and functional elements

22

17a
17b

Mains power cable with plug for circulator
Mains power cable with plug cooling machine

18

Built-in mains outlet for connection of circulator (230 V / 16 A)

19

Drain screw with drain connection

20

Venting grid, removable

21
22

Pump connections

suction pump

pressure pump

23

Selector dial for cooling machine (only F25)
Position "1" for operation with HL circulator.

24

Cooling water OUTLET and INLET.

¾"
