Operating procedures

28

6. Operating

procedures

6.1. Power

connection

Caution:

 Only connect the unit to a power socket with earthing contact (PE – protective

earth)!

 The power supply plug serves as safe disconnecting device from the line and must

be always easily accessible.

 Never operate equipment with damaged mains power cables.

 Regularly check the mains power cables for material defects (e.g. for cracks).

 We disclaim all liability for damage caused by incorrect line voltages!


Check to make sure that the line voltage matches the supply voltage
specified on the identification plate.

 Connect the circulator with mains power cable (17a) to the mains

outlet (18).

 Connect the control cable (9) to the  sockets (9a, 9b).
 Connect the refrigerated circulator with mains power cable (17b) to

the mains socket.

6.2. Switching on / Selecting the language

6.2.1.

Switching on the circulator

Switching on:

 Turn on the mains power switch (1a).

The unit performs a self-test.
Then the software version (example: V 1.xx-xxxx) appears. The
display „OFF“ or „R OFF“ indicates the unit is ready to operate.

The circulator enters the operating mode activated before switching
the circulator off:
keypad control mode

(manual operation) or

remote control mode

(operation via personal computer).

Selecting the language:
There are two options for the language of the LCD DIALOG-DISPLAY:
German or English. Select the desired language in the menu
>Configuration< under the submenu >Language/Sprache<.
Press the respective keys in the following order:

3x up to menu Configuration

6x up to submenu >Language/Sprache<

deutsch / english
