General view -3, General view – Brother HL-1260E User Manual
Page 29
CHAPTER 2 GETTING STARTED
2–3
General View
A
B
Fig. 2-3 Front View
Fig. 2-4 Rear View
Top Cover
Multi-purpose Tray
Face Down Print
Delivery Tray
Font/IC Card Slot
Font Cartridge Slot
Upper Paper Cassette
Power Switch
Control Panel
Power Cord Connector
Bi-directional Parallel
Interface Connector
RS-232C Serial
Interface Connector
MIO Card Slot
Rear Access Cover
Adjustment Knob for
Face Up/Down Print Delivery
Modular Jack for Options
