PM-700 SERIES PLATING MONITOR
62
To terminate the automatic data logging, the host computer would send the
following message:
Header
(2 bytes)
Instruction Code
(1 byte)
Message
Length
(1 byte)
Command
Code or
Message Checksum
(1 byte)
FFh FEh 50h 1h 0h AEh
4.8.4.5.2 Single data log
This operation allows the computer to initiate a single data log function.
To a single data log function, the computer would send a one byte message in the
standard format. The variables will be sent in the order they are displayed in
above. For example, to setup the monitor to automatically output the displayed
rate and thickness, the following message would be sent to the monitor:
Header
(2 bytes)
Instruction Code
(1 byte)
Message
Length
(1 byte)
Command
Code or
Message Checksum
(1 byte)
FFh FEh 60h 1h 3h 9Bh
