PM-700 SERIES PLATING MONITOR
39
4.5.4
Restoring to Default Values
The four material parameters, Tooling Factor, Density, Acoustic Impedance and
ElecChem can be reset to their factory set default values by pressing the Status
button while both the Up and Down arrow buttons are depressed.
4.6 STATUS
ASSESSMENT
4.6.1 Monitor
Status
The monitor status can be assessed any time by pressing the Status button. When
the Status button is pressed, the following list of status parameters are displayed in
the Parameter/Status display:
Simulate
mode
Monitor
state
Process
Number
Top Left display quantity
Top Right display quantity
PRM/STATUS display quantity
Sample mode (ON/OFF)
Deplate mode (Manual/Auto)
Probe Swap mode (Manual/Auto)
Bath Type (Electro/Elecless)
Material (Bath Material)
Time units (Hours/Minutes/Seconds)
Thickness units (K
Χ
/
µ
inch/Micron/
µ
g per cm
2
/mg per cm
2
)
Crystal type (6 Mhz/5 Mhz/3 Mhz/2.5 MHz)
4.6.2 Probe
Status
Pressing the Probe status button results in the display of the following
information: crystal frequency type and health, crystal frequency in Megahertz, the
plating mode of the crystal, and the plating rate on the crystal.
The crystal frequency and type is displayed in the Rate display area.
The crystal frequency, in Megahertz, is displayed in the Thickness display area.
The Probe mode and the plating rate are displayed alternately in the
Parameter/Status display area.
