MDC-370 DEPOSITION CONTROLLER
Table of Input states for BCD feedback type.
Pocket
Number Input
BCD2 Input
BCD1 Input
BCD0
1 OPEN OPEN OPEN
2 OPEN OPEN GND
3 OPEN GND OPEN
4 OPEN GND GND
5 GND OPEN OPEN
6 GND OPEN GND
7 GND GND OPEN
8 GND GND GND
7. Rotator Delay (0 to 99 seconds)
This parameter serves two different functions. If the feedback type is “None”
(Not recommended. See cautions in the Installation section) this parameter tells
the controller how long to wait, on the assumption the pocket will get into
position. If position feedback is provided, this parameter tells the controller how
long it should wait for the pocket to reach its target position before it issues a
Source Fault message.
8. Source Voltage (2.5V, 5.0V, 10V)
This parameter sets the upper voltage range for the source control output. The
lower voltage range is always 0. For example, selecting 10 for this parameter sets
the source control voltage range from 0 to 10 volts.
4.3.3.7 EDIT DAC SETUP
Selecting Edit DAC Setup from the Edit System Setup menu will present the
DAC Setup screen that allows selection of the parameter and its signal range for
each of the two DACs.
PROGRAMMING AND CONTROLLER SETUP 4-41
