CrystalSix Operating Manual
1.1.2 Materials
1.1.3 Unpacking Instructions
The CrystalSix sensor and accessories are packaged in a single cardboard carton
with rigid foam inserts.
Carefully remove the packaged accessories before removing the sensor, then
remove the red shipping plug from the sensor carousel.
1.1.4 Inventory
In addition to the basic transducer, the complete shipping package includes an
accessory kit (IPN 750-268-G1) which consists of the following:
Table 1-2 Materials
Plate, Holders, Material Shield,
Mechanical Parts 304 type stainless steel
Springs, Electrical Contacts Au plated Be-Cu, Au Plate Inconel®, 303
stainless steel
Water and air tubes S-304, 0.125" (0.32 cm) O.D. x .016" (.04
cm) Wall Thickness 30" Long (76 cm)
Seamless Stainless Steel Tubing
Connector (Microdot) Stainless steel
Insulators >99% A1
2
O
3
Cable Teflon® insulated copper
Crystal 0.550" Diameter
Body and Carousel 2024 T351 Aluminum
Table 1-3 Contents of Accessory Kit
Qty IPN Description
X 750-268-G1 Accessory Kit, CrystalSix Sensor
1 750-254-G1 Assembly, Alignment Tool
1 750-279-P1 Crystal Puller
1 074-5000-G1 Thin Film Manuals CD
1 008-010-G10 Assembly, Sensor Crystal 6MHz
1 059-189 CC-1010-0225 Orifice 0.0225" diameter
2 070-201 #4 Split Lock Washer, Stainless Steel
2 084-032 #4-40x0.375" Long Socket Head Cap Screw, Stainless Steel
