1 General Information
Please read this Operating Manual carefully before putting your Sensistor ILS500 F
into service. When reading, please pay particular attention to the WARNINGS,
CAUTIONS and NOTICES found throughout the text.
1.1 About This Manual
The purpose of this manual is to:
• Describe the working principles of the ILS500 F and its different parts
• Show examples of different types of test stations
• Teach the reader how to set up the ILS500 F for different test purposes
1.1.1 Document History
1.2 Introduction to the ILS500 F
The Sensistor ILS500 F is a stand alone tracer gas filler with all necessary functions
integrated in one very compact housing.The purpose of the ILS500 F is to make it
possible to set up a fully automatic leak test system quickly, to a low cost.
The ILS500 F can also be combined with both hydrogen and helium INFICON leak
detectors.
If a ISH2000 Hydrogen Leak Detector is connected to the ILS500 F, via the Probe
Control Port and Leak Detector Port, the ILS500 F has the same functionality as
ILS500. For information on how to setup this configuration, please contact INFICON.
1.2.1 Intended Use
ILS500 F is designed for indoor use only.
All functions are accessible and programmable using a touch panel, a PC or via the
Internet. The test sequence is controlled by an integrated controller.
Revision Date Remark
a 10-2014 First edition
Notice ILS500 F is not compatible with AP29, AP55, and AP57.
