ILS500 F Description
12
ninp69e1-a (1410)
3
ILS500 F Description
ILS500 F is manually controlled using the START and STOP buttons and the menu
system of the touch panel. The screen also shows the steps of the test sequence
graphically and in plain text.
3.1
Front View
ILS500 F Front View
1
Red lamp
2
Green lamp
3
ILS500 F Touch panel
4
START button
5
STOP button
1
2
3
4
5
