76 Technical Data
ninp69e1-a (1410)
Commands
The printer port can also be used to control the ILS500 F. The most commonly used
functions can be started/configured over the RS232 interface. Always use New Line
(0A,LF) as end character.
11.4.2 Input 1 (Optional)
Command Action
K<0A> Starts a calibration. If the function is busy, the ILS500 prints the
time remaining for the ongoing calibration in seconds. For
example, if two seconds remains the printout is as follows:
WAIT 2 <0A>
S<0A> Statistics (see table below)
RS<0A> Reset statistics
R<09> Factory Default <0A> loads a recipe. For example
“R<09>Factory Default” loads the recipe Factory Default. When
the recipe is loaded the recipe name is echoed back. If a recipe
name isn’t in the ILS500, the answer from the ILS500 will be
“Not a recipe name!”
Statistics Printed data Explanation
REC:AP29 - recipe name. Printed if recipes is activated
TOT:00031 - total
ACC:00009 - accepted
REJ:00022 - rejected
EVA:00001 - evacuation
VDE:00000 - vacuum decay
BLO:00006 - blockage test
FIL:00001 - gas filling
PRE:00000 - pressure decay
GAS:00014 - gas detector
