Recipes
44
ninp69e1-a (1410)
Pressure Decay Test
7.3.4
Tracer Gas Filling
Pressure Stabilisation Time
Pressure Decay Test Time
Pressure Decay Limit
5.0
5.0
0.10
s
s
bar
Gas Pressure Decay Test
Pressure Stabilisation Time
Delay time before Pressure Decay test begins.
Pressure Decay Test Time
Time during which pressure drop is recorded.
Pressure Decay Limit
Allowed pressure drop during test time.
Warning
The ILS500 F must never be introduced to pressures higher than that approved for
the object to be tested and never beyond the ILS500 F specification.
Notice
Ensure that the test object has time to become filled before Fill Time Out
expires. In particular long narrow objects, as pipes, may need long filling
time.
Tracer Gas Filling
Fill Setpoint
Fill Timeout
External Fill Regulation
Pressure Unit
5.00
10.0
bar
bar
s
Fill Setpoint
Desired tracer gas fill pressure.
Fill Timeout
Object will be rejected if Pressure Setpoint has not
been attained within this time.
Cancels the fill if the test object has a major leak,
opens, or if there are loose connections.
