INFICON Sensistor ILS500F Leak Detection System - Manual (Page 38)

Recipes 38
ninp69e1-a (1410)
7 Recipes
A recipe is a collection of settings suited for a particular test setup. This is used to have
different settings for different test objects.
7.1 Recipe Overview
Click Settings >> Recipes to enter the three Recipe Setup menus.
Load Recipe
Save Recipe Delete Recipe
Use Recipes
Choose at startup
Recipe Setup
Recipe Setup
Connect with recipe
Use from list Factory Default
Keep Tooling in Test Step
Keep Pressure in Test Step
0
Import from USB
Export to USB
Recipe Setup
USB Memory connected
Use Recipes Select the box to activate the recipe handling.
Choose at Startup When power is switched on, the ILS500 F prompts
the operator to choose recipe.
Load Recipe Loads the parameters of chosen recipe.
A new window will open.
Save Recipe Saves the current settings under chosen recipe
name.
A new window will open.
