Medical Compressed Gas Connectors
MediMate cga 870 and cga 950 operatIon
step 3
Connecting to the cylinder:
• A three step process locks the valve into place.
Figure 7. Valve properly aligned.
Figure 8. Connector in transition.
Figure 9. Fully connected.
